1991 Mazda Miata - Detail 2.0 (Paint Correction+Write-up)
« on: August 16, 2014, 10:15:26 am »
It has been sometime since my last detailing write-up so I thought it was time to post one even though it was a small detail. This detail was part of a facebook giveaway for the Illmotion Sunday School Show & Shine 2014. The winner received my Exterior Protection detail.

Here we have a 1991 Mazda Miata. Overall the vehicle was in pretty good shape with minor scuffs but it was evident that the vehicle has not been detailed in sometime. My detailer OCD kicked in on this one because I couldn't stand how dirty the single stage paint was. I decided to throw in a polished hood into this detail to see how much clarity would be revealed.

Process

Exterior:

Wheels: 1z Colortec Wheel Cleaner with various brushes
Tires: Zep Formula 505 Cleaner & Degreaser
Wheel Wells: Zep Citrus Cleaner (4:1)
Pre-wash: CG Citrus Wash & Gloss via foam cannon
Wash: CG Citrus Wash & Gloss via 2BM & Wool Wash Mitt
Decontamination: Carpro Trix (Iron and Tar Remover)
Dry: Waffle Weave Towels
Polish (Hood Only): Blackfire Total Polish & Seal w/ Tangerine Hydrotech Pads via Rupes LHR15ES (5.5” pads)
Paint Protection: Wolfgang Deep Gloss Paint Sealant 3.0
Tire Dressing: Optibond Tire Gel
Trim Dressing: Wolfgang Exterior Trim Sealant
Glass: Stoner Invisible Glass with Rain Repellent via Glass Towel
Exhaust Polishing: P21s Polishing Soap
Wheel Polishing: P21s Polishing Soap
Wheel Sealant: Blackfire Crystal Seal

Total Time: 6 Hours

Before Photos:















During Photos:













After Photos:























Thanks for viewing and enjoy!



2003 Mazda Miata
2015 WRX Build
2004 Forester XT Build

“When you see the tree you’re about to hit, it’s called under steer. When you can only feel and hear it, it’s over steer.”

Offline jellynuts

  • Vendor
  • Rivaling ZZ-TOP
  • *
  • Posts: 8168
  • Delay No More
  • Location: Airdrie
  • Ride: 07 STI, 15 Odyssey
Amazing.  Thank you for these threads.  I know the entire process is time consuming, but I love just scrolling through the pictures and, "through the miracle of time," finished product.
uckfay, Johnny with the back-handed slap. You're clearly the Oracle.

Check out my work on:  Instagram  FaceBook  Flickr  YouTube

Offline LilDrunkenSmurf

  • Rivaling ZZ-TOP
  • *****
  • Posts: 19319
  • This is why I can't own nice things..
  • Location: Calgary
  • Ride: hopefully doesn't trigger ekai
Same here. It also makes me wish I had an excuse to come to Edmonton, and you weren't booked up for the next 18 years.
If the sea was vodka, and I was a duck.
I would swim to the bottom, and drink my way up.
But the sea isn't vodka, and I'm not a duck.
So give me the vodka, and stfu.
If you're having forum problems, I feel bad for you son, I got 99 problems but your post ain't one.

Offline 10secdream

  • Moderator
  • Rivaling ZZ-TOP
  • ****
  • Posts: 4298
    • ReflectiveAutoDetailing
  • Location: Sherwood Park, Alberta
  • Ride: 2022 Toyota GR86, 2007 Lexus GX470
Same here. It also makes me wish I had an excuse to come to Edmonton, and you weren't booked up for the next 18 years.

If you help with the vehicle detail we could probably do this in 1 day. I am sure you can figure out some excuse to come to Edmonton.
2003 Mazda Miata
2015 WRX Build
2004 Forester XT Build

“When you see the tree you’re about to hit, it’s called under steer. When you can only feel and hear it, it’s over steer.”

Offline 10secdream

  • Moderator
  • Rivaling ZZ-TOP
  • ****
  • Posts: 4298
    • ReflectiveAutoDetailing
  • Location: Sherwood Park, Alberta
  • Ride: 2022 Toyota GR86, 2007 Lexus GX470
Thanks for the kind words. This was a fun detail to do for an awesome event.
2003 Mazda Miata
2015 WRX Build
2004 Forester XT Build

“When you see the tree you’re about to hit, it’s called under steer. When you can only feel and hear it, it’s over steer.”

Offline 10secdream

  • Moderator
  • Rivaling ZZ-TOP
  • ****
  • Posts: 4298
    • ReflectiveAutoDetailing
  • Location: Sherwood Park, Alberta
  • Ride: 2022 Toyota GR86, 2007 Lexus GX470
Re: 1991 Mazda Miata - Detail 2.0 (Paint Correction)
« Reply #5 on: March 16, 2015, 09:39:18 pm »
The owner brought the vehicle back for a complete paint correction. I am very happy with how it is turning out.



The trunk was also recently painted and here is how it looks finished out.

2003 Mazda Miata
2015 WRX Build
2004 Forester XT Build

“When you see the tree you’re about to hit, it’s called under steer. When you can only feel and hear it, it’s over steer.”

Offline 10secdream

  • Moderator
  • Rivaling ZZ-TOP
  • ****
  • Posts: 4298
    • ReflectiveAutoDetailing
  • Location: Sherwood Park, Alberta
  • Ride: 2022 Toyota GR86, 2007 Lexus GX470
Re: 1991 Mazda Miata - Detail 2.0 (Paint Correction)
« Reply #6 on: March 19, 2015, 08:15:54 pm »
This week I performed a 1 step correction (paint enhancement) on a previous clients 1991 Mazda Miata.
The single stage paint was a pleasure to work with and it is awesome to see the vehicle white like it was 25 years ago.

Process
Exterior:
Wash: ONR via Microfiber Towels
Decontamination 1: CarPro PolyShave Towel
Dry: Waffle Weave Towels
Tape: 3m Automotive Tape
Paint Thickness: Taken using Digital Coating Thickness Gauge
Polish: Scholl Concepts S30+ w/ Orange Buff n Shine Pads via Rupes LHR15ES (5.5” pads) and GG6 (4” pads)
Surface Prep: DP Prep Polish
Paint Protection: Black Label Surface Coating

During Photos:

I performed my test spot on the front fender to figure out what combination of pad and product would yield the best results. Sure enough the combination I used on my previous detail did the trick. Not only was the paint swirled it was very oxidized (due to being neglected single stage paint). Not only were the defects removed but the clarity and color of the paint was enhanced.











After Photos:











Enjoy
2003 Mazda Miata
2015 WRX Build
2004 Forester XT Build

“When you see the tree you’re about to hit, it’s called under steer. When you can only feel and hear it, it’s over steer.”

Offline Markkenko

  • Vendor
  • Rivaling ZZ-TOP
  • *
  • Posts: 2499
  • Location: British Columbia
  • Ride: 1998 Version 5 Subaru Impreza WRX STI Type R V-Limited
Re: 1991 Mazda Miata - Detail 2.0 (Paint Correction+Write-up)
« Reply #7 on: March 19, 2015, 08:23:39 pm »
Veeery nice!

Offline 10secdream

  • Moderator
  • Rivaling ZZ-TOP
  • ****
  • Posts: 4298
    • ReflectiveAutoDetailing
  • Location: Sherwood Park, Alberta
  • Ride: 2022 Toyota GR86, 2007 Lexus GX470
Re: 1991 Mazda Miata - Detail 2.0 (Paint Correction+Write-up)
« Reply #8 on: March 19, 2015, 08:24:56 pm »
Don't mind the temporary wheels ;D. Thanks for the kind words.
2003 Mazda Miata
2015 WRX Build
2004 Forester XT Build

“When you see the tree you’re about to hit, it’s called under steer. When you can only feel and hear it, it’s over steer.”

Offline Dr Beans

  • Beards Comin in Nice
  • ****
  • Posts: 904
  • Location: Edmonton
  • Ride: 2018 Canyon & 2001 STI
Re: 1991 Mazda Miata - Detail 2.0 (Paint Correction+Write-up)
« Reply #9 on: March 19, 2015, 08:34:18 pm »
It's crazy to see the colour difference side by side like that.

Offline LilDrunkenSmurf

  • Rivaling ZZ-TOP
  • *****
  • Posts: 19319
  • This is why I can't own nice things..
  • Location: Calgary
  • Ride: hopefully doesn't trigger ekai
Re: 1991 Mazda Miata - Detail 2.0 (Paint Correction+Write-up)
« Reply #10 on: March 20, 2015, 07:04:13 am »
Man, that's much better. I hope seat safety switch doesn't see this, he might get some bad ideas.
If the sea was vodka, and I was a duck.
I would swim to the bottom, and drink my way up.
But the sea isn't vodka, and I'm not a duck.
So give me the vodka, and stfu.
If you're having forum problems, I feel bad for you son, I got 99 problems but your post ain't one.

Offline ultimatt

  • WSC Supporter
  • Rivaling ZZ-TOP
  • *****
  • Posts: 2936
  • Thrusting in the direction of the problem.
  • Location: Edmonton
  • Ride: Thundercougarfalconbird
Re: 1991 Mazda Miata - Detail 2.0 (Paint Correction+Write-up)
« Reply #11 on: March 20, 2015, 09:53:00 am »
Yeah. He wants to practice power polishing on my beater miata for some reason.
<+  Hurrbie> becuase ultimasshole

Offline 10secdream

  • Moderator
  • Rivaling ZZ-TOP
  • ****
  • Posts: 4298
    • ReflectiveAutoDetailing
  • Location: Sherwood Park, Alberta
  • Ride: 2022 Toyota GR86, 2007 Lexus GX470
Re: 1991 Mazda Miata - Detail 2.0 (Paint Correction+Write-up)
« Reply #12 on: March 20, 2015, 10:06:51 am »
Yeah. He wants to practice power polishing on my beater miata for some reason.

Got to start somewhere....
2003 Mazda Miata
2015 WRX Build
2004 Forester XT Build

“When you see the tree you’re about to hit, it’s called under steer. When you can only feel and hear it, it’s over steer.”

Offline ultimatt

  • WSC Supporter
  • Rivaling ZZ-TOP
  • *****
  • Posts: 2936
  • Thrusting in the direction of the problem.
  • Location: Edmonton
  • Ride: Thundercougarfalconbird
Re: 1991 Mazda Miata - Detail 2.0 (Paint Correction+Write-up)
« Reply #13 on: March 20, 2015, 10:09:05 am »
he has his own beaters!

anyway, i wish my white miata looked this good.
<+  Hurrbie> becuase ultimasshole

Offline 10secdream

  • Moderator
  • Rivaling ZZ-TOP
  • ****
  • Posts: 4298
    • ReflectiveAutoDetailing
  • Location: Sherwood Park, Alberta
  • Ride: 2022 Toyota GR86, 2007 Lexus GX470
Re: 1991 Mazda Miata - Detail 2.0 (Paint Correction+Write-up)
« Reply #14 on: March 20, 2015, 10:14:31 am »
Vehicle is in very good condition considering the age. Sigh. (Really wants a Clean Miata now....)
2003 Mazda Miata
2015 WRX Build
2004 Forester XT Build

“When you see the tree you’re about to hit, it’s called under steer. When you can only feel and hear it, it’s over steer.”

Offline chico_kj_23

  • Beards Comin in Nice
  • ****
  • Posts: 611
  • Location: Sherwood Park
  • Ride: 1993 WRX, 2011 G37X, 2018 4Runner
Re: 1991 Mazda Miata - Detail 2.0 (Paint Correction+Write-up)
« Reply #15 on: March 20, 2015, 02:21:00 pm »
Dat camber tho :o

Paint looks fantastic though! To bad they color matched his trunk to the previous, uncorrected paint.

Offline 10secdream

  • Moderator
  • Rivaling ZZ-TOP
  • ****
  • Posts: 4298
    • ReflectiveAutoDetailing
  • Location: Sherwood Park, Alberta
  • Ride: 2022 Toyota GR86, 2007 Lexus GX470
Re: 1991 Mazda Miata - Detail 2.0 (Paint Correction+Write-up)
« Reply #16 on: March 20, 2015, 02:49:09 pm »
I got the whole story and the painter color matched the trunk to the old mirrors because the vehicle was in storage for the winter. His plan is to get the front fenders and trunk resprayed.
2003 Mazda Miata
2015 WRX Build
2004 Forester XT Build

“When you see the tree you’re about to hit, it’s called under steer. When you can only feel and hear it, it’s over steer.”

Offline 05LGT

  • Rivaling ZZ-TOP
  • *****
  • Posts: 4471
  • Trained Trunk Monkey
  • Location: Calgary Alberta
  • Ride: Toyota Echo RS
Re: 1991 Mazda Miata - Detail 2.0 (Paint Correction+Write-up)
« Reply #17 on: March 20, 2015, 02:49:36 pm »
Dang if my Miata was more...dent free I would totally send it to you for that.

Looks amazeballs.
I don't name things I know I'm going to sell eventually. Hence why I'd never name any kids I had.

If you can't go fast with 90HP, 900HP won't help you. - Bob Hall

Offline 10secdream

  • Moderator
  • Rivaling ZZ-TOP
  • ****
  • Posts: 4298
    • ReflectiveAutoDetailing
  • Location: Sherwood Park, Alberta
  • Ride: 2022 Toyota GR86, 2007 Lexus GX470
Re: 1991 Mazda Miata - Detail 2.0 (Paint Correction+Write-up)
« Reply #18 on: March 20, 2015, 02:51:02 pm »
Dang if my Miata was more...dent free I would totally send it to you for that.

Looks amazeballs.

I can make the BRZ shiny for you :D
2003 Mazda Miata
2015 WRX Build
2004 Forester XT Build

“When you see the tree you’re about to hit, it’s called under steer. When you can only feel and hear it, it’s over steer.”

Offline Stealthbombing

  • Beards Comin in Nice
  • ****
  • Posts: 976
  • Location: Calgary
  • Ride: BMW 135i M
Re: 1991 Mazda Miata - Detail 2.0 (Paint Correction+Write-up)
« Reply #19 on: March 20, 2015, 03:55:30 pm »


how much of a hard on do you get when you reach this step of detailing a car.  To me, these foamy pictures are the best no matter what car is hiding underneath
*** PM Me for quotes on parts for wholesale price !!***
Stella -
http://www.westernsubaruclub.com/smf/index.php?topic=47765.msg579306#msg579306


Offline 10secdream

  • Moderator
  • Rivaling ZZ-TOP
  • ****
  • Posts: 4298
    • ReflectiveAutoDetailing
  • Location: Sherwood Park, Alberta
  • Ride: 2022 Toyota GR86, 2007 Lexus GX470
Re: 1991 Mazda Miata - Detail 2.0 (Paint Correction+Write-up)
« Reply #20 on: March 25, 2015, 08:05:30 am »
Foam pictures are very satisfying. Glad you enjoy them as well.
